Fair 4.1" Wide Black 24VDC 200W LED Dimmable Power Supply
For Information: 800-782-1967 or
- 8" wide x 4.1" deep x 3.1" high.
- Hardwire 24VDC energy-efficient LED magnetic dimmable power supply by SlimEdge™.
- Black powder-coated.
- Transformer is encapsulated in all metal NEMA 3R rated enclosure. Enclosure temperature should not exceed 70-degree C (158-degree F) @ 40-degree C (104-degree F) ambient.
- Wiring compartment has three knockouts sized for 3/4" screw cable connectors.
- Wiring compartment cover is hinged with rivets and opens vertically from bottom to top.
- Thermal class B-130C. Inputs leads are 18AWG, output leads are 12AWG.
- Lead insulation rated to 105-degree C (221-degree F). Transformer utilizes a class B 130-degree C (266-degree F) insulation system.
- Max wattage is 200 watts. Output is 24V.
- Works with all dimmers that provide symmetrical form of the current under any conditions.
- No minimum load (can be fully loaded).
- Manual reset thermal 14A circuit breaker on the secondary side.
- Surface mount with back mounting tab.
- UL listed for indoor use only.
This 24VDC energy-efficient LED magnetic dimmable power supply by SlimEdge™ can handle a maximum load of 200 watts. It's encapsulated in an all metal construction enclosure. The power supply is compatible with all dimmers providing symmetrical current and features a manual thermal reset circuit breaker on its secondary side.
| Finish | Black |
|---|---|
| Type | Direct Wire |
| Color | Black |
| Height | 3.10 inches |
|---|---|
| Depth | 8.00 inches |
| Manufacturer Number | LTHM200-DIM-24 |
