Image 1 Fair 4.1" Wide Black 24VDC 300W LED Dimmable Power Supply

Fair 4.1" Wide Black 24VDC 300W LED Dimmable Power Supply


Product Not Available

For Information: 800-782-1967

Notify me when this becomes available:

Plus you'll get great deals & offers to your inbox!
Product Details
  • 9" wide x 4.1" deep x 3.1" high.
  • Hardwire 24VDC energy-efficient LED magnetic dimmable power supply by SlimEdge™.
  • Black powder-coated.
  • Transformer is encapsulated in all metal construction enclosure. Enclosure temperature should not exceed 65-degree C (149-degree F) @ 40-degree C (104-degree F) ambient.
  • Wiring compartment has three knockouts sized for 3/4" screw cable connectors.
  • Wiring compartment cover is hinged with rivets and opens vertically from bottom to top.
  • Thermal class B-130C. Input leads are 18 AWG. Output leads are 12 AWG.
  • Lead insulation rated to 105-degree C (221-degree F). Transformer utilizes a class B 130-degree C (266-degree F) insulation system.
  • Max wattage is 300 watts. Output is 24V.
  • Works with low-voltage magnetic wall dimmer with on-off switch.
  • No minimum load (can be fully loaded).
  • Manual reset thermal 4A circuit breaker on the primary side.
  • Coil former is double section bobbin.
  • Surface mount with back mounting tab.
  • UL listed for indoor and outdoor use.

This 24VDC energy-efficient LED magnetic dimmable power supply by SlimEdge™ can handle a maximum load of 300 watts. It's encapsulated in an all metal construction enclosure. The power supply is compatible with all dimmers providing symmetrical current and features a manual thermal reset circuit breaker on its secondary side.

Product Attributes
Finish Black
Type Direct Wire
Color Black
Technical Specifications
Manufacturer Number LTHM300-DIM-24
