Thompson 3.86" Wide 24VDC 100W Electronic LED Power Supply

- Style # 24P21
$127.80
  • Free Shipping*
  • Low Price Guarantee
In stock Ships in 1 to 2 Days
Add to Cart

Maintain a clean area near your lighting system with this SlimEdge™ power supply with four mounting clips.

More Details >
Thompson 3.86" Wide 24VDC 100W Electronic LED Power Supply
Thompson 3.86&quot; Wide 24VDC 100W Electronic LED Power Supply
Product Details

This power supply with four mounting clips by SlimEdge™ features a metal chassis with screw terminals and mounting feet for convenient installation. The 120V input is standard for most lighting systems and complements 100-watt output. The short circuit, overload, and over voltage protection ensures proper safety during use.

  • 3.86" wide x 7" deep x 1.75" high.
  • 24VDC energy-efficient LED electronic power supply with four mounting clips by SlimEdge™.
  • Fully epoxy encapsulated for long life. Full metal enclosure. No external fusing required.
  • Max wattage is 100 watts. 24VDC output. 120-240 VAC input. 47 - 63Hz frequency range at 84 percent typical efficiency. 4.2 amps.
  • LED indicator for power on. High operating temperature up to 70-degree C (158-degree F). Metal chassis with screw terminals and mounting feet.
  • Features short circuit, overload, and over voltage protection.
  • 110 - 150 percent rated output power overload protection.
  • Overload recovers automatically after fault condition is removed.
  • Built-in constant current limiting circuit. 100 percent full load burn-in test.
  • Fixed switching frequency at PFC:67KHz, PWM:134KHz.
  • Recommended for commercial applications.
  • UL listed for indoor use only.
