Thompson 4" Wide 24VDC 200W Electronic LED Power Supply


This product has been discontinued and is not available.

For Information: 800-782-1967 or

Product Details
  • 4" wide x 9" deep x 2" high.
  • 24VDC energy-efficient LED electronic power supply by SlimEdge™.
  • Full metal enclosure. No external fusing required.
  • Max wattage is 200 watts. 24VDC output. 85 - 264 VAC input. 47 - 63Hz frequency range at 83 percent typical efficiency. 8.4 amps.
  • LED indicator for power on. High operating temperature up to 70-degree C (158-degree F). Screw terminals and mounting feet. Built-in cooling fan speed control.
  • Features short circuit, overload, and over voltage protection.
  • 105 - 150 percent rated output power overload protection.
  • Overload recovers automatically after fault condition is removed with constant current limiting.
  • 100 percent full load burn-in test. Over voltage protection 26.4 - 32.4V.
  • Recommended for commercial applications.
  • RU/CE listed for indoor use only.

This 24VDC power supply with a built-in cooling fan by SlimEdge™ features a metal enclosure with screw terminals and mounting feet for convenient installation. The power supply features 85-264VAC input that complements 200-watt output and is recommended for commercial applications. The short circuit, overload, and over voltage protection ensures proper safety during use.

Specifications

Product Attributes
Type LED
Color Silver
Technical Specifications
Manufacturer Number LTH24-8
